Description
● WSLP-635-005m-4-PD
● Wavelength: 638nm
● Output power: 5mW
● Package: Coaxial
● Fiber core: 9um
● Fiber length: 80cm
● Connector: FC/SC/SMA905 optional
● Built-in PD
| Specifications | WSLP-635-005m-4-PD | ||
| Min | Type | Max | |
| Center Wavelength@25℃ | 630nm | 638nm | 645nm |
| Spectral Width (FWHM) | —- | 2.0nm | —- |
| Output Power | 5mW | ||
| Fiber Type | Single Mode Fiber | ||
| fiber core | 9um | ||
| Recommend Operating Temperature | —- | 25°C | |
| Monitor Current | 0.3mA | ||
| PD Reverse Voltage | 30V | ||
| Fiber Connector | —- | FC/SC/SMA905 | |
| Fiber Length | —- | 80cm | 100cm |
| Threshold Current (Typ.) | —- | 40mA | 60mA |
| Operating Current(Typ.) | 80mA | 100mA | |
| Operating Voltage | 2.4V | 2.7V | |
| Package Style | Coaxial or B82 | ||
| Built-in PD | |||
