Description
- Type: Other
- Origin: Mainland China
- Place of Origin: Zhejiang, China
- Condition: New
- Warranty: 1 Year
- After-sales Service Provided: Online support
- Spare Parts Type: diode
- Video outgoing-inspection: Provided
- Machinery Test Report: Provided
- Marketing Type: Hot Product 2019
- Key Selling Points: Long Service Life
- Showroom Location: None
- Applicable Industries: Machinery Repair Shops, Home Use, Printing Shops
- Weight (KG): 1 KG
- Output power: 3mW
- Wavelength: 670nm
- Lifetime: over 10000hours
- Application 1: Test equipment
- Application 2: Optical transmitter of data signal
- Application 3: Optical transmitter of analog signal
- Application 4: Optical Bidi module and optical transceivers
Product Description
3mW 670nm SM Single Mode Fiber Coupled Diode Laser with Photodiode
Features
670nm SM Laser Diode
Fiber Coupled Coaxial Package
4um Single Mode Fiber
FC/PC Connector
3mW Output Power, Single Mode
3mW 670nm Single Mode Fiber Coupled Diode Laser is Fabry-Perot laser with integrated photodiode. The FC670SM3 diode laser features a low threshold current and high slope efficiency resulting in a low operating current enhancing reliability.
Specification
Item No.: FC670DL3
Item Name: 3mW 670nm Fiber Coupled Diode Laser
|
Optical
|
|
|
Center Wavelength
|
670nm
|
|
Wavelength Tolerance
|
±10nm
|
|
Output Power
|
3mW
|
|
Fiber
|
|
|
Fiber Core Diameter
|
4um
|
|
Fiber Numerical Aperture
|
0.12NA
|
|
Fiber Length
|
1m
|
|
Fiber Connector
|
FC/PC
|
|
Electrical
|
|
|
Operating Current Iop
|
20mA
|
|
Threshold Current Ith
|
40mA
|
|
Operating Voltage Vop
|
2.5V
|
|
Thermal
|
|
|
Operating Temperature
|
0~60℃
|
|
Storage Temperature
|
-40-70℃
|
Drawing
