808nm~810nm 10mW SM Pigtailed Laser diode with Coaxial Package | Built-in Photodiode

$229.00

Categories: ,

Description

●  WSLP-808-020m-4-PD
●  Wavelength: 808nm
●  Output power: 10mW
●  Package: B15
●  Fiber core: 9um
●  Fiber length: 80cm
●  Connector: FC/SC/SMA905 optional
●  Built-in PD

Specifications WSLP-808-020m-4-PD
                    Min Type Max
Center Wavelength@25℃ +/-5nm 808nm +/-10nm
Spectral Width (FWHM) —- 2.0nm —-
Output Power 10mW
Fiber Type Single Mode Fiber
fiber core 9um
Recommend Operating Temperature —- 25°C
Monitor Current 0.1mA
PD Reverse Voltage 30V
Polarization Extinction Ratio
Fiber Connector —- FC/SC/SMA905
Fiber Length —- 80cm 100cm
Threshold Current (Typ.) —- 25mA 55mA
Operating Current(Typ.) 110mA 130mA
Operating Voltage 2.0V 2.4V
Package Style B15
         Built-in PD
