Description
● Part Number：WSLD-808-010-E
● Wavelength：808nm
● Output Power：10W
● Package：E-mount
● Without PD & FAC
|
Part Number
|
WSLD-808-010-E
|
|||
| PARAMETER | SYMBOL | VALUE | UNIT OF MEASURE | |
| Reverse Voltage | Vr | 2.0 | V | |
| Operating Temperature | Top | +10~+30 | °C | |
| Storage Temperature | Tstg | -20~+80 | °C | |
| Lead Soldering Temperature (10 sec.) | Tis | 260 | °C | |
|
Typical Specification (@25C°)
|
Min.
|
Typical Value
|
Max.
|
|
| Optical Parameters
|
Center Wavelength
|
808nm+/-10nm
|
||
|
Output Power
|
—- | 10.0W | —- | |
| Spectral Width(FWHM) | —- | 2.0nm | —- | |
| Wavelength Temp. Coefficient | 0.3nm/°C | |||
| Laser Type | FP | |||
| Beam Type | Multimode | |||
| Emitter Size | 200um x 1um | |||
| Beam Divergence (FWHM) | —- | 35°⊥x8°∥ | —- | |
| Slope Efficiency | —- | 1.15W/A | —- | |
| Electrical Parameters | Threshold Current | —- | 1.5A | 2.5A |
| Operating Current | —- | 10.5A | 11.0A | |
| Operating Voltage | —- | 1.9V | 2.4V | |
| Photodiode Parameters | Photodiode | Without | ||
| PD Current | —- | —- | —- | |
| PD Reverse Voltage (Max.) | —- | |||
| Other Parameters | Package | E-mount | ||
| Recommended Operating Temp. |
25°C | |||
|
Other |
—- | |||
