Description

808nm 3W Pigtailed Diode Laser WSLX-808-003-H-T-PD MM Pigtailed LD.808nm 3W WSLX-808-003-H MM Pigtailed LD

● 808nm Pigtailed Diode Laser With MM Fiber

● ＞3W Output Power

● 105um or 200um Multi-mode Fiber

● 9-Pin Package

● Build-in PD

● Built-in TEC cooler

● FC/SC/SMA05 connector optional

Center Wavelength@25℃: Min: ±3nm, Type: 808nm, Max: ±10nm

Spectral Width (FWHM): Type: 3nm

Output Power: Typical: 3.5W

Temperature Coefficient of Wavelength: 0.3nm / °C

Threshold Current (Typ.): 0.5A

Operating Current (Typ.): 6.0A

Operating Voltage: Type: 2.0V

Recommended Operating Temperature: 25°C

Fiber Core Diameter: 105um(200um 400um Optional)

Fiber Numerical Aperture: 0.22 (0.15 0.37 Optional)

Fiber Length: 100cm

Connector Type: FC (SMA905 Optional)

Package Style: 9-pin

TEC Cooling: Built-in

Built-in Photodiodes: Built-in
