Description
- Brand Name: LanYuXuan
- Origin: Mainland China
- DIY Supplies: ELECTRICAL
- Certification: CE
- Place of Origin: Beijing, China
- Condition: New
- Warranty: 1 Year, 1 year
- After-sales Service Provided: Video technical support, Online support
- Spare Parts Type: vcsel diode laser stack
- Video outgoing-inspection: Provided
- Machinery Test Report: Provided
- Marketing Type: hot product 2021
- Brand Name: oriental
- Key Selling Points: High Safety Level
- Showroom Location: Russia
- Applicable Industries: Other
- Weight (KG): 1 KG
- Service: Repairing / Refurbishment
- Laser Bar: vcsel laser bar
- Per Bar Power: 65w/chip
- Cooling system: Micro Channel Cooling
- Spot Size: 12.7*12.7mm
- Center wavelength: 808 -8
- Water flow: >3.0L/min
- Drift Coefficients: 0.07nm/℃
- Threshold current: Threshold current
My friend, welcome to our store, if you need other models of this product, please contact me WhatsApp +8615111224853, I will send the product link for you to buy
Product Description
Vcsel Diode Laser Details Usage
1. Hair removal machine
2. Laser power from 300W-1200W
3. Other customized power or design
Please Contact Me
Product Paramenters
|
Model No.
|
OL-VSL-1004
|
|
Peak power
|
65w/chip
|
|
Spot size
|
12.7×12.7mm
|
|
Center wavelength
|
808+-8
|
|
Drift Coefficients
|
0.07nm/℃
|
|
Threshold current
|
10A
|
|
Max.Current
|
65A
|
|
Max.Working voltage
|
2.1V/chip
|
|
Repetition frequency
|
1-10Hz
|
|
Max. Duty cycle
|
60%
|
|
Max.Pulse width
|
400ms
|
|
Environment temperature
|
15-35℃
|
|
Best water temperature
|
20-25℃
|
|
Storage temperature
|
-20-60℃
|
|
Water flow
|
>3.0L/min
|
|
Hydraulic pressure
|
0.4-0.6MPa
|
|
Water requirement
|
Pure water or deionized water.Conductivity 10us/cm.resistivity ≥1MΩ*cm.Particulate matter≤20um.
|
Our Advantages
1. Higher laser power
2. Smaller divergence angel and more uniform light spot
3. Lower drift coefficient and narrower spectral width
4. Symmetrical spot , easy to shape
5. Higher stability and reliability
6. Large water water channel for heat dissipation,high cooling ability
7. Fully sealed nitrogen filling treatment, strong environment adaptability.
2. Smaller divergence angel and more uniform light spot
3. Lower drift coefficient and narrower spectral width
4. Symmetrical spot , easy to shape
5. Higher stability and reliability
6. Large water water channel for heat dissipation,high cooling ability
7. Fully sealed nitrogen filling treatment, strong environment adaptability.
The chip in the black box is intact
We have this raw material and production strength.
We have the ability to repair
The picture is that the customer’s item is broken and sent to us for repair.
After repair
It can emit light normally.
Maintenance Service
We can repair variety brand diode laser stack and lase handle
With email or whatsapp , you can send us picture or video to show me the problem about the handpiece. When confirm the repair service, the repair process as: A.Deliver the problem laser diode handle or laser diode stack B.Our technician check the laser, and we will offer you quotation for free service C.You can confirm to repair the laser handle or laser diode head D.We will change the damage laser bar to new bars E.We will send you test report and video and also picture for new laser head or laser handle after refurbishment F.We will pack the fixed laser head or laser handle and then deliver to you
Company Introduction
Oriental-laser is the professional manufacturer of aesthetic & medical laser machine . It is the beauty equipment manufacturer which owns specialty on diode laser cosmetic technique and the unique independent diode laser chip packaging technology in the world. Oriental-laser pay more attention on R&D and keep strict manufacture management continuously. we have a facility of 500 square feet of class 10K clean room & class 1000 local clean zone (according to Federal Standards 209E). After using our product and solution, Oriental- laser’s customer won the rich profits and praise and this is why Oriental-laser accumulated a stable customer base around the world. In the future, we continue to insist on “Through using our excellent quality and outstanding performance product to help our customers to gain maximum profit”and pay more efforts to provide quality products and service for more customers
FAQ
|
Warranty
|
1 year.
|
|
|
During the period, if any problems of machine, please contact us. We will do our best at the earliest time.
|
|
Payment
|
T/T, Western Union, MoneyGram, PayPal etc.
|
|
|
100% in advance,please pay transfer fee in your side.
|
|
Delivery
|
By express (DHL, EMS, UPS, TNT, Fedex etc.), by air express to airport, by sea.
|
|
|
Delivery time is 3- 7 days after payment.
|
|
Certificate
|
Our products have acquired CE Certificate and ISO 9001 Certificate.
|
|
OEM & ODM
|
We are professional diode laser beauty machine manufacturer.
|
|
|
We can offer OEM&ODM service.
|
