Description

850nm 1.5W Pigtailed Diode Laser WSLX-850-001-H MM Pigtailed LD.WSLX-850-001-H MM Pigtailed LD

● 850nm Pigtailed Diode Laser With MM Fiber

● 1.5W Output Power

● 105um or 200um Multi-mode Fiber

● 4-Pin Package

● Build-in PD optional

● Built-in TEC cooler optional

● FC/SC/SMA05 connector optional

Center Wavelength@25℃: 850±10nm

Spectral Width (FWHM): 3nm

Output Power: Typical: 1.5W

Temperature Coefficient of Wavelength: 0.3nm / °C

Threshold Current (Typ.): 0.3A

Operating Current (Typ.): 2.4A

Operating Voltage: 2.0V

Recommend Operating Temperature: 25 °C

Fiber Core: 105um (200um 400um Optional)

Fiber Numerical Aperture: 0.22

Fiber Length: 100cm

Connector Type: SMA905/ST/FC

Package Style: 4-pin
