Description
Hamamatsu S8650 Flat surface ideal for bonding to scintillator
The S8650 Si PIN photodiode has an epoxy coating window processed to have a flat surface (flatness: ±5 μm). When bonded to a scintillator, the flat surface allows highly tight coupling to the scintillator so bubbles are unlikely to penetrate in between. We also accept special orders for machining flat surfaces on other ceramic package products. Feel free to place an order with us.
Features
– Flat epoxy coating surface ideal for bonding to scintillator
Flatness: ±5 μm
– Photosensitive area: 10 × 10 mm
Specifications
| Photosensitive area | 10 × 10 mm |
|---|---|
| Package | Ceramic |
| Package category | For X-ray detection |
| Cooling | Non-cooled |
| Reverse voltage (max.) | 100 V |
| Spectral response range | 340 to 1100 nm |
| Peak sensitivity wavelength (typ.) | 960 nm |
| Photosensitivity (typ.) | 0.66 A/W |
| Dark current (max.) | 6000 pA |
| Cutoff frequency (typ.) | 40 MHz |
| Terminal capacitance (typ.) | 40 pF |
| Noise equivalent power (typ.) | 3.8×10-14 W/Hz1/2 |
| Measurement condition | Ta=25 ℃, Typ., Photosensitivity: λ=λp, Dark current: VR=70 V, Cutoff frequency: VR=70 V, Terminal capacitance: VR=70 V, f=1 MHz, Noise equivalent power: VR=70 V, λ=λp, unless otherwise noted |
