Description

WSLP-425-001-M MM Pigtailed LD

● 425nm Pigtailed Diode Laser With MM Fiber
● 1W Output Power
● 105um Multi-mode Fiber
● 0.22N.A.
● Coaxial Package
● Fiber Receptacle optional
● FC/SC/SMA05 connector optional

Center Wavelength@25℃: Min: 415nm, Typical:425nm,Max:435nm

Output Power (CW Mode): Typical: 1W

Fiber Type: Multi-mode Fiber

Fiber Core: 105um (50um, 200um Optional)

Recommend Operating Temperature: 25℃

Fiber Connector: FC/ST/SMA905/SC

Fiber Length: Typical: 80cm

Threshold Current (Typ.): Typicial: 150mA

Operating Current (Typ.) For CW Mode: Typicial: 800mA

Operating Voltage: Typicial: 4.5V

Package: Coaxial
