976nm~980nm 50MW Single Mode LD with 5.6mm TO18 Package

$49.00

Categories: ,

Description

●  Part Number:WSLD-980-050m-1-PD
●  Wavelength:980nm
●  Output Power:50mW
●  Package:TO18 (5.6mm)
●  Built-in PD

Part Number
WSLD-980-050m-1-PD
PARAMETER SYMBOL VALUE UNIT OF MEASURE
Reverse Voltage Vr 2.0 V
Operating Temperature Top -10~+40 °C
Storage Temperature Tstg -40 ~ +85 °C
Lead Soldering Temperature (10 sec.) Tis 260 °C
Typical Specification (@25C°)
Min.
Typical Value
Max.
Optical Specifications

Center Wavelength
976nm+/-15nm
Output Power
—- 50mW —-
Spectral Width(FWHM) —- 2.0nm —-
Wavelength Temp. Coefficient 0.3nm/°C
Laser Type FP
Beam Type Single Mode
Beam Divergence(FWHM) —- 35°⊥x15°∥ 40°⊥x20°∥
Slope Efficiency —- 0.8mW/mA —-
Electrical Specifications Threshold Current —- 15mA 30mA
Operating Current —- 75mA 85mA
Operating Voltage —- 1.6V 2.2V
Photodiode Specifications Photodiode Built-in
PD Current —- 0.3mA —-
PD Reverse Voltage (Max.) 30V
Other Specifications Package Style TO18 (5.6mm)
Recommended
Operating Temp.
25°C

Other

—-
