Photoresistor (LDR) Sensor Module Detects Light Sensitive Photodiode for Arduino


171 in stock

SKU: 32452315745 Category:


  • Brand Name: DIKAVS
  • Usage: Photoelectric
  • Type: Humidity Sensor
  • Theory: Optical Sensor
  • Output: Switching Transducer
  • Model Number: Photoelectric Sensor
  • Material: Mixture
  • is_customized: Yes




  Sensitive sensors using photoresistor

  The comparator output signal clean, good waveform, driving ability, more than 15mA.
  With adjustable potentiometer to adjust the brightness of the light detection
  Operating voltage 3.3V-5V
  Output Type: Digital switching output (0 and 1)
  With fixed bolt hole for easy installation
  Small PCB board size: 3.2cm x 1.4cm
  Use a wide voltage LM393 comparator
Module for use
  Photosensitive resistor module most sensitive to ambient light, generally used to detect the brightness of ambient light, triggering microcontroller or relay modules;
  When the brightness of ambient light module can not reach the set threshold, DO-side output high when the ambient light level exceeds the set threshold, DO end output low;
  DO output can be directly connected to the microcontroller through the microcontroller to detect high and low, thereby detecting the brightness of ambient light to change;
  DO output of the relay module can directly drive the shop, which can be composed of a light control switch


Package Included:

1 X Photosensitive resistor module
